Slot mortising attachment VDA315L
Designed as an accessory to a range of machines. Equipment includes chuck, cast iron table with guiding in transverse and longitudinal direction controlled by one lever.
Product code: 6519401612000
Technical parameters
| Max. tool diameter | Ø 16 mm |
| Max. height of splints above the table | 125 mm |
| Range of longitudinal movement | 180 mm |
| Range of lateral movement | 135 mm |
| Length | 385 mm |
| Width | 474 mm |
| Height | 870 mm |
| Table dimensions | 460 x 190 mm |
| Dimensions with packaging | 560 x 510 x 420 mm |
| Gross weight | 40 kg |
| Net weight | 37 kg |
| Workplace noise (without technology) | + |
| Workplace noise (with technology) | + |
| Acoustic performance (without technology) | + |
| Acoustic performance (with technology) | + |
Warranty conditions
- 12 months
